Ozone Aging Test Chamber
下載
資料 點(diǎn)擊
觀看
發(fā)送詢問
資料 點(diǎn)擊
觀看
Ozone aging test chamber simulates and strengthens the ozone conditions in the atmosphere to test the ozone aging resistance and aging crack test of non-metallic materials and organic materials, such as paints, paints, rubber, plastics, etc.
| Model | YOT-080 | YOT-150 | YOT-1000 |
|---|---|---|---|
| Inside dimensions W*H*D (cm) | 40*50*40 | 50*60*50 | 100*100*100 |
| Outside dimensions W*H*D (cm) | 90*140*95 | 100*150*105 | 150*190*155 |
| Temperature range | RT~80℃ | ||
| Temperature fluctuation | ±0.5℃ | ||
| Temperature uniformity | ±1.5℃; Empty load, 30 mins after stanlization | ||
| Resolution | 0.01℃ | ||
| Ozone concentration | 0~1000PPHM, adjustable (Optional: 0~500ppm non-standard) | ||
| ozone control precision | ±10% | ||
| Ozone production mode | Ozonator | ||
| Sample frame | Static and Dynamic fixtures | ||
| Sample frame speed | 360° rotation (1 circle/minute | ||
| Material | SUS#304 Stainless steel for inner chamber, cold rolled sheet + powder coating for external chamber | ||
| Insulation | PU | ||
| Circulation system | Cooling fan | ||
| Heating system | SUS# stainless steel high speed heater | ||
| Controlling system | Digital electrinic indicator + SSR+ PID | ||
| Refrigeration system | compressor + Fin type evaporator + air/water cooling system | ||
| Ozone concentration analyzer | Imported ozone concentration analyzer | ||
| Ozone generator | Silent discharge ozone generator | ||
| Other components | 1. Muti-layer vacuum glass obvervation window | ||
| 2. Controlling status indicator lamp 3. Chamber light | |||
| Safety protection device | 1. Over-heat protection 2. phase sequence protection 3. overload protection | ||
| Power supply | AC 1ψ220V; 3ψ380V 60/50Hz | ||
| Customization service | Non-standard or special requirements are all welcome | ||
